Features
- Turret
- Oil pressure operating
- Available flow: over 4,000 LPM
- Illumination tower
- Wire or wireless control available
- HID-XENON type lamp
- High performance water pump
- 1 stage centrifugal pump
- Bronze material
- Pump-N-Roll mode available
- Automatic transmission (optional)
- Pump-N-Roll mode available
- Dry Powder System
- Two tanks with each 150kgs capacity
- Hi-advanced automatic water turret
- Wireless remote control with touch screen apart from max. 80m.
- Available flow: max. 7,000 LPM
- Bumper turret
- Very effective for where adjustable speed and automatic oscillation
are needed.
- Vertical travel 80° above and 40° below
- 180° Horizontal travel
- Flow maximum 3,000 LPM
- Auxiliary engine(optional)
- Engine for Pump-N-Roll mode
Specifications
|
MODEL
|
ARFFV(6X6) (N 2000)
|
ARFFV(4X4) (N 1000)
|
|
OVERALL LENGTH(mm)
|
10,950
|
10,250
|
|
OVERALL WIDTH(mm)
|
2,495
|
←
|
|
OVERALL HEIGHT(mm)
|
3,800
|
←
|
|
WHEEL BASE(mm)
|
5,900
|
←
|
|
ENGINE(ps/rpm)
|
650/2,300
|
←
|
|
PUMP CAPACITY(ℓ/min)
|
5,650
|
←
|
|
WATER TANK(ℓ)
|
10,000
|
5,600
|
|
FOAM TANK(ℓ)
|
1,200
|
800
|
|
DRY CHEMICAL(Kg)
|
300
|
←
|
|
|
|
|
| |
|
|
|
